By Vetus

Vetus Flexible Coupling BULLFLEX16 for 40mm Shaft

€1.246,94
€1.246,94
Tax included.

More driving comfort through reduced vibrations: The Vetus Bullflex 1 is a specially developed flexible coupling that efficiently dampens torsional vibrations between the engine and the propeller shaft. The super elastic, pre-tensioned rubber element ensures a play-free, noiseless connection – even at low speeds and changing engine loads.

Tip: Vetus supplies suitable mounting material for attachment to the gearbox separately – ask for the appropriate accessories when ordering. The centering ring can be removed if necessary to facilitate installation in confined spaces.
brand: Vetus
Availability: Low stock
SKU: OB-BB-BULFL1640
Product group:
category:
Engine technology
VetusVetus Rubber Bearing with Brass Sleeve 1 1/2"
Vetus Gummilager mit Messingmantel 1 1/2'
Ritchie Sport
Ritchie NavigationRitchie Sport, black, black dial
Vetus Flexible Kupplung BULLFLEX16 f. 40mm Welle
€1.246,94
€1.246,94

  • Super-elastic rubber element efficiently dampens torsional vibrations – for noticeably quieter engine operation
  • Backlash-free connection between engine and shaft ensures low-noise running
  • Axial and radial fail-safes protect the connection even in case of overload
  • Angular deviation of up to 2° permissible – shaft remains centered even with deviation and in reverse operation
  • Built-in thrust bearing and no conical clamping hub for easy assembly and disassembly
  • 4" connection (models 1, 2 and 4) – suitable for common gearboxes

Model Bullflex 1
Shaft diameter 25 mm
Connection flange 4"
Maximum angular misalignment 2°
Fail-safe device axial and radial
Thrust bearing built-in
Clamping hub no tapered clamping hub
Suitable for V-drives No
Matching gearboxes (model 32) Hurth, Velvet, TD, ZF, P.R.M.
Brand Vetus

Vetus

Gewicht (ca.): 18.64 kg
