By Ritchie Navigation
Ritchie Sport, black, black dial
Regular price
€68,33
Regular price
Sale price
€68,33
Unit price
per
Tax included.
Small, precise, and ready for immediate use: The RitchieSport fits into any standard instrument hole and provides a clear direct reading – by day and, thanks to integrated NiteVu lighting, also at night. For sport boats where every inch counts, it is the clever navigation reference on the dashboard.
Tip: The X-23 models do not have built-in compensators. When installing, check that interfering magnetic sources (speakers, electrical cables) are sufficiently far away from the compass to minimize deviation errors. The green 12V lighting can be replaced with optional lamps in red, clear, or blue if required – part numbers are listed below in the specification table.
Couldn't load pickup availability
brand:
Ritchie Navigation
Availability:
Low stock
SKU:
OB-BB-X-23BB
Product group:
category:
Navigation & Audio
Regular price
€68,33
Regular price
Sale price
€68,33
- Fits standard 2 1/16″ (5.50 cm) instrument holes – quick installation without modifications
- Direct-reading dial with 51 mm diameter – readable at a glance
- Viewing angle adjustable up to 30 degrees – flexible adaptation to your sitting position
- Exclusive green NiteVu illumination (12 V) – navigate safely at night at all times
- DirectiveForce magnets and hardened steel pivot dial movement – reliable course indication even with vibrations
- High-temperature composite construction – extended operating temperature range for harsh onboard conditions
| Dial Diameter | 2″ (51 mm) |
|---|---|
| Mounting Size (Cutout) | 2 1/16″ (5.50 cm) |
| Readout | Direct Read |
| Viewing Angle | Adjustable up to 30 Degrees |
| Lighting | Built-in NiteVu Lighting, 12V Green (Standard) |
| Magnet Type | DirectiveForce Magnets |
| Dial Movement | Hardened Steel Pivot Movement |
| Optics | Scientifically Matched Sapphire Jewel |
| Case | High-Temperature Composite Construction |
| Compensators | Not Built-in (Model X-23) |
| Color / Dial | Black / Black |
| Warranty | 5 Years (Ritchie Exclusive) |
| Approx. Shipping Weight | 142 g (5 oz.) |
| Replacement Bulb 12V Green | RS-0148 GRN |
| Replacement Bulb 12V Red | RS-0148 ROT |
| Replacement Bulb 12V Clear | RS-0148 WHT |
| Replacement Bulb 12V Blue | RS-0148 BLU |
Ritchie Navigation
Gewicht (ca.): 0.44 kg
