Victron MultiPlus-II 12/3000/120-32 230V
The Victron MultiPlus-II 12/3000/120-32 is the heart of any serious 12V onboard power system: it combines a powerful 3000VA inverter, a 120A battery charger, and intelligent power management in a single compact device. Thanks to PowerControl and PowerAssist, you get the most out of your shore power or generator connection – without overloading the fuse. With integrated anti-islanding and country approvals, it also meets the requirements for grid-connected systems.
Tip: For full use of PowerControl and self-consumption optimization, an external current transformer is required – check before installation whether this is already present in your system or needs to be purchased separately.
Couldn't load pickup availability
- 3000 VA inverter power for demanding 230V consumers on board
- 120 A integrated battery charger for fast, gentle charging
- PowerAssist prevents fuse tripping by intelligently adding battery capacity
- External current transformer (max. 32 A) enables PowerControl and self-consumption optimization
- Integrated anti-islanding and country approvals for grid-connected installations
- Combines the functions of MultiPlus and MultiGrid in one device
| Model | MultiPlus-II 12/3000/120-32 |
|---|---|
| Input voltage (DC) | 12 V |
| Inverter power | 3000 VA |
| Charge current | 120 A |
| External current transformer (max.) | 32 A |
| Output voltage (AC) | 230 V |
| Function | Inverter + Charger + Anti-Islanding |
| PowerControl | Yes (with external current transformer) |
| PowerAssist | Yes (with external current transformer) |
| Self-consumption optimization | Yes (with external current measurement) |
| Anti-Islanding | Integrated |
| Country approvals | Yes (selection continuously growing) |
Victron Energy
Gewicht (ca.): 22.5 kg
