By Johnson Pump
Johnson HD Bilge Pump L4000/24V
Regular price
€291,96
Regular price
Sale price
€291,96
Unit price
per
Tax included.
When it counts, the bilge pump must pump immediately and reliably – the Johnson HD bilge pump L4000 is built for exactly that. With a pumping capacity of up to 252 l/min (4000 GPH) at 24 V, it effortlessly removes even critical amounts of water on board. Liquid-cooled 12-pole motor with double ball bearings ensures long service life even in continuous operation.
Tip: Secure with a 15 A fuse (manufacturer's recommendation) and choose a minimum cable cross-section of 2 mm² – for long cable runs, dimension accordingly larger to avoid voltage drop.
Couldn't load pickup availability
Regular price
€291,96
Regular price
Sale price
€291,96
- Up to 252 L/min (4000 GPH) flow rate – reliable backup in emergencies
- 12-pole, liquid-cooled motor with double ball bearings for maximum service life
- Mechanical shaft seal reduces wear and simplifies maintenance and replacement
- Two connection sizes (38 mm / 50 mm) for flexible installation
- Stainless steel shaft (SS2343) for permanent corrosion protection
- Meets and exceeds recreational and commercial marine requirements
| Voltage | 24 V |
|---|---|
| Flow rate at 0 m head (27 V) | 252 l/min – 4000 GPH |
| Flow rate at 0.9 m head (27 V) | 164 l/min – 2600 GPH |
| Power consumption | 7.5 A |
| Recommended fuse | 15 A |
| Cable diameter | 2 mm² |
| Cable length | 1.8 m |
| Connection | 1½" (38 mm) and 2" (50 mm) |
| Shaft material | Stainless steel SS2343 |
| Motor design | 12-pole, liquid-cooled, double ball bearing |
| Shaft seal | Mechanical seal |
| Max. diameter | 121 mm |
| Max. height | 216 mm |
| Weight | 2.45 kg |
Johnson Pump
Gewicht (ca.): 2.95 kg
