Johnson Aqua-Jet WPS 5.2 Pump 24V/2.8bar/20L
Calm water on board, without noisy pump humming: The Johnson Pump Aqua-Jet WPS 5.2 supplies your boat with constant water pressure thanks to its five-chamber diaphragm technology, with significantly less noise and pulsation development than conventional three- or four-chamber pumps. With a flow rate of 20 l/min and a shut-off pressure of 2.8 bar, it is ideal for small boats and recreational vehicles.
Tip: Be sure to connect a PumpProtector™ inlet filter before the pump inlet – this is not included in the scope of delivery. This protects the diaphragm from dirt particles and significantly extends the service life of the pump. Shut-off pressures of 2.1 bar/30 PSI and 1.4 bar/20 PSI as well as NPT connections are available on request.
Couldn't load pickup availability
- Five-chamber diaphragm technology – noticeably quieter and with less pulsation than 3 or 4-chamber pumps
- 20 l/min flow rate for reliable water supply on board
- Automatic shut-off pressure at 2.8 bar – pump switches on automatically when pressure drops
- Santoprene diaphragm and EPDM valves for high durability and chemical resistance
- Compact PP housing – lightweight and corrosion-resistant
- 24V version – suitable for larger on-board power systems
| Model | Aqua-Jet WPS 5.2 |
|---|---|
| Voltage | 24 V |
| Motor Power | 150 W |
| Flow Rate | 20 l/min (5.2 GPM) |
| Shut-off Pressure | 2.8 bar (41 PSI) |
| Diaphragm | Santoprene |
| Valves | EPDM |
| Housing | PP (Polypropylene) |
| Number of Chambers | 5 |
| Fusing | 8 A |
| Connection | ¾″ BSP / Hose ½″ and ½″ BSP / Hose ¾″ |
| Dimensions (L × W × H) | 240 × 214 × 110 mm |
| Weight | 2 kg |
