Scanstrut ROKK USB socket SC-USB-03 Input 12/24V Output 1x USB-A + 1x USB-C 2x3A Waterproof according to IPX6

Splashproof (IPX4) charging socket with 1x USB-A and 1x USB-C port for ultra-fast charging: with up to 36W for 12-volt systems and up to 60W for 24-volt systems, it is ideal for charging laptops, for example. Simultaneous fast charging of an iPhone and an iPad is also no problem.

The USB socket allows you to charge up to two devices simultaneously, regardless of weather conditions. The spring-loaded IPX4-rated cover effectively protects the socket from water. The housing is made of durable, UV-resistant plastic, the hinge and spring are made of stainless steel (AISI 316), and all internal contacts are made of a nickel-plated copper alloy.

Specifications:

• IPX4 waterproof when the cover is closed
• UV-resistant plastic
• Hinge and spring made of AISI 316 stainless steel
• Input voltage 10 - 32 V DC (12/24 Volt system)
• USB-C output: 60 W max. for 24-volt systems, 36 W max. for 12-volt systems
• USB-A output: 36 W max.
• Total charging current: 6 A, 3 A per socket

Dimensions (assembled):
Width: 39.0 mm
Height: 94.0 mm
Depth 29.0 mm

Installation dimensions:
Hole diameter: 29 mm
Wall thickness: max. 25 mm
