By Veratron

Veratron VDO VMH-35_D Multifunction Color Display

€456,79
€456,79
Tax included.

Everything your diesel engine wants to tell you - on a single display. Veratron's VMH-35D combines engine data, battery monitoring, tank, and GPS in one compact unit, keeping you informed at all times. Thanks to its integrated 10 Hz GNSS receiver and NMEA 2000 certification, it is the complete bridge solution between analog sensors and a modern onboard network.

Tip: Use the analog/CAN-to-NMEA 2000 interface to integrate existing analog sensors (e.g., older tank senders) into the NMEA 2000 network - saving you additional converters.
brand: Veratron
Availability: Low stock
SKU: OB-BB-B00171101
Product group:
category:
Navigation & Audio
Veratron VDO VMH-35_D Multifunktions-Farbdisplay
€456,79
€456,79

  • Over 30 displayable data channels – engine, battery, tank, and GPS combined in one device
  • Integrated 10 Hz GNSS receiver provides speed, position, and course without additional equipment
  • NMEA 2000 certified – converts analog and CAN signals directly into NMEA 2000 data
  • SAE J1939 CAN bus for diesel engines with configurable RPM scale (3,000 or 4,000 RPM)
  • 4 analog inputs for external sensors and EasyLink output for up to 16 VMH-14 satellite instruments
  • Operates on 12V and 24V vehicle electrical systems – universally applicable

Model VMH-35D
Operating Voltage 12 V / 24 V
GNSS Receiver Integrated, 10 Hz
Certification NMEA 2000
Bus Protocol SAE J1939 CAN
Analog Inputs 4 (for external sensors)
EasyLink Output For up to 16 VMH-14 satellite instruments
Interface Analog / CAN to NMEA 2000
Displayed Data Values Over 30
Tachometer Scale Configurable: 3,000 or 4,000 RPM
Alarm Function Configurable via SAE J1939 or local menu
Display Content Engine, battery, tank, GPS (speed, position, course)

Veratron

Gewicht (ca.): 0.28 kg
