By Selden

Seldén Stemball Terminal with UNF Thread – Threaded Terminal for Rigging

€15,90 - €219,90
Tax included.

Precision at the end of the wire rope: The Seldén Stemball Terminal reliably connects your standing rigging to turnbuckles and tensioners. The spherical bearing surface compensates for angular misalignments, ensuring even load distribution throughout the rig.

Cups and turnbuckles are not included and must be ordered separately – please consider this when assembling your rigging kit.

€15,90
€15,90 €15,90
brand: Selden
Availability: Low stock
SKU: SE-308-560
Product group:
category:
Rig & Deck > Rigging > Terminals
Seldén Stemballterminal mit UNF-Gewinde – Gewindeterminal für die Takelage
€15,90
€15,90 €15,90

  • Stainless steel – corrosion-resistant and permanently seawater-proof
  • Spherical stemball compensates for angular misalignments and reduces stress peaks
  • UNF threads in common sizes from 1/4 to 7/8 inch for broad compatibility
  • Matching radius for each thread size for an optimal fit in the turnbuckle
  • Original Seldén quality for reliable standing rigging

Material Stainless Steel
Thread Type UNF
Available Thread Sizes 1/4 Inch, 5/16 Inch, 3/8 Inch, 7/16 Inch, 1/2 Inch, 5/8 Inch, 3/4 Inch, 7/8 Inch
Stemball Radius per Size R6 (1/4), R9 (5/16, 3/8), R11 (7/16, 1/2), R14 (5/8), R18 (3/4, 7/8)
Scope of Delivery Terminal without Cups and Turnbuckles

Selden

Gewicht (ca.): 0.2 kg
