Scanstrut ROKK Flip-Pro USB socket SC-USB-F1 Input 12/24V Output 1x USB-A 1x USB-C 5V each 3A Waterproof according to IPX4

Splashproof (IPX4 with closed lid) charging socket with 1x USB-A and 1x USB-C port for ultra-fast charging: with up to 36W for 12-volt systems and up to 60W for 24-volt systems, it is ideal for charging laptops, for example. Simultaneous fast charging of an iPhone and an iPad is also no problem.

The spring-loaded IPX4 lid effectively protects the box from splashing water and rain. The housing is made of a robust and UV-resistant plastic, the hinge and spring are made of stainless steel (AISI 316), and all internal contacts are made of a nickel-plated copper alloy.

Specifications:

• IPX4 waterproof when the cover is closed
• UV-resistant plastic
• Hinge and spring made of AISI 316 stainless steel
• Input voltage 10 - 32 V DC (12/24 Volt system)
• USB-C output: 60 W max. for 24-volt systems, 36 W max. for 12-volt systems
• USB-A output: 36 W max.
• Total charging current: 6 A, 3 A per socket

Dimensions (assembled):
Width: 37.7 mm
Height: 39.0 mm
Depth 17.8 mm

Installation dimensions:
Drill hole diameter: 28.2 mm
Wall thickness: min. 3 mm, max. 25 mm
