No more dirty floats and jammed linkages: The Philippi UTV 50 measures the level in your tank completely contact-free using ultrasound – with no moving parts in the medium. This is the cleanest, lowest-maintenance solution on board, especially for greywater and blackwater tanks.

Tip: When cruising in rough seas or with a strong heel, the ultrasonic signal may be temporarily disturbed – Philippi therefore does not recommend this type of sensor for fuel tanks. For those who want to improve the measurement quality even while underway, the Philippi UFT sound guide tube can be optionally retrofitted.
brand: philippi
Availability: Low stock
SKU: OB-BB-702193550
Product group:
category:
electrical system
Philippi UTV 50
€140,30
€140,30

  • Non-contact ultrasonic technology – no moving parts in the tank that can get dirty or damaged
  • Ideal for black and grey water tanks – no contact with tank contents
  • Compatible with analog and digital gauges thanks to 0.5 V–2.5 V output signal
  • Wide supply voltage range 10–30 V – fits almost any on-board electrical system
  • Easy replacement for conventional tank sensors with SAE standard mounting (5 holes, 53 mm bolt circle)
  • Extreme temperature range –40 °C to 85 °C for reliable operation in any climate

Type Ultrasonic Tank Sensor UTV 50
Output Signal 0.5 V – 2.5 V
Supply Voltage 10 – 30 V
Current Consumption 50 mA
Temperature Range –40 °C to 85 °C
Mounting SAE standard, 5 holes, bolt circle 53 mm
Measuring Principle Ultrasonic, non-contact
Suitable for Greywater and blackwater tanks
Compatibility Analog and digital measuring instruments

philippi

Gewicht (ca.): 0.08 kg
