By philippi

Philippi UTV 30

€140,30
€140,30
Tax included.

No more clogged floats and sticking linkages: The Philippi UTV 80 measures the fill level of your tank using ultrasound – completely contact-free and without a single moving part in the tank. Especially for black water tanks and grey water tanks, it is the clean, low-maintenance solution on board.

Tip: When heeling or in choppy seas, the ultrasonic measurement can become inaccurate – this is due to physics. For better measurement quality even while underway, Philippi recommends the optional installation of a sound guide tube UFT. The UTV 80 is generally not suitable for fuel tanks.
brand: philippi
Availability: Low stock
SKU: OB-BB-702193530
Product group:
category:
electrical system
Philippi UTV 30
€140,30
€140,30

  • Contactless ultrasonic technology – no moving parts in the tank, no fouling, no jamming
  • Ideal for black water tanks and grey water tanks, where conventional sensors quickly fail
  • Compatible with analogue and digital measuring instruments – universally applicable
  • Direct replacement for existing tank sensors with SAE standard mounting (5 holes, bolt circle 53 mm)
  • Wide supply range 10–30 V – suitable for 12 V and 24 V on-board power systems
  • Extreme temperature range from -40 °C to 85 °C for continuously reliable operation

Type Philippi UTV 80
Measuring Principle Ultrasound, non-contact
Suitable for Greywater tanks, holding tanks
Compatibility Analog and digital measuring instruments
Mounting SAE standard, 5 holes, 53 mm bolt circle
Supply Voltage 10–30 V
Current Consumption 50 mA
Temperature Range −40 °C to 85 °C
Accessories (optional) UFT sound guide tube for improved measurement while underway

philippi

Gewicht (ca.): 0.08 kg
