By philippi

Philippi UTV 25

€140,30
€140,30
Tax included.

No more clogged floats and sticking linkages: The Philippi UTV 80 measures the fill level of your tank using ultrasound – completely contact-free and without a single moving part in the tank. It is the clean, low-maintenance solution on board, especially for sewage tanks and greywater tanks.

Tip: When tilted or in choppy waters while underway, ultrasonic measurement can become inaccurate – this is due to physics. For better measurement quality even while underway, Philippi recommends the optional installation of a UFT sound guide tube. The UTV 80 is generally not suitable for fuel tanks.
brand: philippi
Availability: Low stock
SKU: OB-BB-702193525
Product group:
category:
electrical system
Philippi UTV 25
€140,30
€140,30

  • Non-contact ultrasonic technology – no moving parts in the tank, no fouling, no jamming
  • Ideal for black water and grey water tanks where conventional sensors quickly fail
  • Compatible with analog and digital gauges – universally applicable
  • Direct replacement for existing tank sensors with SAE standard mounting (5 holes, 53 mm bolt circle)
  • Wide supply voltage range 10–30 V – suitable for 12 V and 24 V electrical systems
  • Extreme temperature range from −40 °C to 85 °C for continuously reliable operation

Type Philippi UTV 80
Measuring Principle Ultrasonic, non-contact
Suitable for Greywater tanks, blackwater tanks
Compatibility Analog and digital measuring instruments
Mounting SAE standard, 5 holes, bolt circle 53 mm
Supply Voltage 10–30 V
Current Consumption 50 mA
Temperature Range −40 °C to 85 °C
Accessories (optional) UFT sound guide tube for improved measurement while underway

philippi

Gewicht (ca.): 0.08 kg
