By philippi

Philippi BHM300

€43,74
€43,74
Tax included.

Reliable control over the entire electrical system: The Philippi BHM300 is a robust battery master switch that allows you to safely disconnect your electrical system – whether in an emergency or when leaving the boat. Thanks to its flexible mounting options, it can be installed as a flush-mount, surface-mount, or panel-mount version.

Tip: The installation diameter is Ø 61 mm – carefully check the available installation depth behind the mounting surface before installation.
brand: philippi
Availability: In stock
SKU: OB-BB-700106006
Product group:
category:
electrical system
€43,74
€43,74

  • 300 A continuous current – designed for high-performance on-board electrical systems
  • 700 A peak current for 9 s – reliably handles short load peaks
  • Usable up to 48 V – compatible with 12 V, 24 V and 48 V systems
  • Three mounting options: recessed, surface, or panel mounting – maximum flexibility
  • M10 connection for secure, low-loss cable connection

Type Philippi BHM300
Continuous Current 300 A
Peak Current 700 A / 9 s
Voltage (max.) 48 V
Design Flush, Surface, or Panel Mount
Connection M10
Dimensions 72 × 72 mm
Mounting Hole Ø 61 mm

philippi

Gewicht (ca.): 0.35 kg
