By Johnson Pump

Johnson Impeller Pump F9B-5600 (DWP376)

€1.651,93
€1.651,93
Tax included.

Full pump power at the touch of a button - without having to be at the pump: The Johnson Pump F9B-5600 is a robust impeller pump with an electromagnetic clutch for heavy-duty on-board operation. The bronze housing, the stainless steel shaft with double ball bearings and the mechanical seal make it a durable choice wherever high flow rates and reliability are important.

Tip: Order the electromagnetic clutch and – for fully automatic dry-running protection – the appropriate vacuum switch separately. For media requiring a nitrile impeller, the pump with impeller 09-814B is available on request. Service kit: 09-45582, Impeller kit: 09-814B.
brand: Johnson Pump
Availability: Low stock
SKU: OB-BB-10-13027-99
Product group:
category:
equipment
Johnson Impellerpumpe F9B-5600 (DWP376)
€1.651,93
€1.651,93

  • Electromagnetic clutch – switches the pump on and off conveniently by remote control or automatically
  • Dry-running protection – in conjunction with a vacuum switch, the clutch disengages automatically as soon as air is sucked in
  • Robust bronze casing with stainless steel shaft and permanently lubricated double ball bearings for continuous heavy-duty use
  • Mechanical seal for reliable sealing even under load
  • Easy maintenance due to easily replaceable wear parts and available service kits
  • Compatible with 12 V and 24 V onboard electrical systems

Model F9B-5600 (DWP376)
Pump Body Bronze
Shaft Stainless steel with permanently lubricated double ball bearings
Shaft Seal Mechanical seal
Cam Full or partial cam
Port Type 2″ BSP
Vacuum Switch Port Present
Clutch Electromagnetic, 12 / 24 V DC (ordered separately)
Pulley 2 × A or 1 × B-groove
Pulley Diameter 178 mm / 7″
Standard Impeller 09-802B
Impeller (nitrile, on request) 09-814B
Weight 13.2 kg
Length 290 mm
Height 192 mm
Width 157 mm
Service Kit 09-45582
Impeller Kit 09-814B

Johnson Pump

Gewicht (ca.): 9.2 kg
