By Johnson Pump

Johnson HD Bilge Pump L1600/24V

€129,39
€129,39
Tax included.

When it comes to bailing, the pump must not fail: The Johnson Pump HD L1600 is a high-performance bilge pump for heavy-duty use in recreational and commercial marine applications. With 100 l/min at free flow and a liquid-cooled 12-pole motor, it performs even where cheaper pumps fail.

Tip: Fuse according to manufacturer's specifications with 6 A and do not extend the enclosed 1.8 m cable (1.3 mm²) without adjusting the cross-section accordingly – otherwise, voltage drop and power loss are imminent.
brand: Johnson Pump
Availability: Low stock
SKU: OB-BB-32-1600-02
Product group:
category:
equipment
Johnson HD-Bilgenpumpe L1600/24V
€129,39
€129,39

  • 100 l/min (1600 GPH) flow rate at 0 m head – reliable even with large amounts of water
  • Liquid-cooled 12-pole motor with double ball bearings for an exceptionally long service life
  • Mechanical shaft seal prevents premature wear and is replaceable
  • Compact design (max. Ø 149 mm) for easy installation in the bilge area
  • Fits hose connections 28 mm (1″) and 32 mm (1¼″) – flexible to install
  • Robust stainless steel shaft (SS2343) for continuous use in saltwater

Voltage 24 V
Capacity (0 m head, 27 V) 100 l/min – 1600 GPH
Capacity (0.9 m head, 27 V) 98 l/min – 1550 GPH
Current draw 3.5 A
Fuse 6 A
Motor type Liquid-cooled, 12-pole
Bearings Double ball bearings
Shaft material Stainless steel SS2343
Shaft seal Mechanical seal, serviceable and replaceable
Hose connection 28 mm (1″) and 32 mm (1¼″)
Max. diameter 149 mm
Cable length 1.8 m
Cable size 1.3 mm² (16 AWG)
Weight 1.3 kg

Johnson Pump

Gewicht (ca.): 1.64 kg
