By Victron Energy

Victron SmartSolar MPPT RS 450/100-MC4

€1.336,25
€1.336,25
Tax included.

If your solar system on board or off-grid gets really big, you need a charge controller that can keep up. The Victron SmartSolar MPPT RS 450/100-MC4 processes solar voltages up to 450 V DC and thus powerfully charges a 48 V battery bank – perfect for demanding, off-grid systems with large, series-connected PV arrays.

Tip: The isolated PV connections significantly increase safety in high-resistance PV arrays – nevertheless, make sure that all cable cross-sections are dimensioned for the chosen system power and activate the integrated overvoltage protection via the charging parameter settings.
brand: Victron Energy
Availability: Low stock
SKU: OB-BB-SCC145110512
Product group:
category:
electrical system
Johnson PumpJohnson Built-in Filters
Johnson Einbaufilter
Victron LiFePO4 Battery 25
Victron EnergyVictron LiFePO4 Battery 25.6V/300Ah NG
Victron SmartSolar MPPT RS 450/100-MC4
€1.336,25
€1.336,25

  • Solar voltage input of 65–450 V DC – ideal for large PV arrays connected in series
  • Designed for 48 V battery banks – efficient charging even of large storage capacities
  • Independent MPPT tracking inputs – maximum yield even with different module orientations
  • Full connectivity (VictronConnect, GX devices) – real-time monitoring and remote access
  • Active cooling and robust metal housing – reliable continuous operation even under load
  • Fully programmable charging parameters – flexibly adaptable to different battery technologies

Manufacturer Victron Energy
Model SmartSolar MPPT RS 450/100-MC4
Battery nominal voltage 48 V DC
Max. solar voltage input (Voc) 450 V DC
Operating solar voltage range 65–450 V DC
Max. charging current 100 A
Max. PV power (5.76 kW model) 5.760 W
Connection type PV MC4
Tracking inputs Independent MPPT tracking inputs
Connectivity VictronConnect (Bluetooth/VE.Can/GX)
Display Integrated screen
Cooling Active
Housing Metal, fully covered electrical connections
PV connections Isolated
Charging parameters Fully programmable
Application Off-grid and grid-connected battery systems
Previous article number SCC145110510

Victron Energy

Gewicht (ca.): 10.0 kg
