By Victron Energy
Victron Quattro-II 24/5000/120-50/50 230V
Regular price
€2.058,64
Regular price
Sale price
€2.058,64
Unit price
per
Tax included.
Two AC inputs, one clever system: The Victron Quattro-II combines an inverter and charger in one device and automatically selects the active input source – whether shore power, generator, or a second external source. With 5000 VA output power, 120 A charging current, and the proven VE.Bus architecture, it is the control center for demanding 24 V onboard electrical systems.
Tip: In combination with a Victron GX device (e.g., Cerbo GX), the Quattro-II can be fully integrated into an ESS or hybrid solar system and remotely monitored via the VRM portal.
Couldn't load pickup availability
brand:
Victron Energy
Availability:
Low stock
SKU:
OB-BB-QUA242505010
Product group:
category:
electrical system
Regular price
€2.058,64
Regular price
Sale price
€2.058,64
- Two independent AC inputs – automatic switching to the active source (e.g. shore power + generator)
- 5000 VA inverter power with true sine wave signal – safe for all sensitive consumers on board
- 120 A adaptive charger – automatically adjusts the charging curve to the battery's condition
- PowerAssist technology – onboard load is supplemented by battery power when the input source is weak, and fuses are never overloaded
- VE.Bus interface – expandable for 3-phase, split-phase, or parallel operation with multiple devices
- 2 × 50 A AC output – consumers can be distributed across two separate outputs
| Model | Quattro-II 24/5000/120-50/50 |
|---|---|
| System voltage | 24 V |
| Inverter output power | 5000 VA |
| Charge current | 120 A |
| AC outputs | 2 × 50 A |
| AC inputs | 2 (automatic transfer switch) |
| Inverter waveform | True sine wave |
| Interface | VE.Bus |
| Operating modes | Standalone, Parallel, 3-phase, Split-phase |
| Technology | Adaptive charging, PowerAssist |
| Nominal output voltage | 230 V AC |
Victron Energy
Gewicht (ca.): 34.0 kg
