By Victron Energy
Victron Phoenix Inverter 12/3000 230V VE.Bus
Regular price
€1.153,11
Regular price
Sale price
€1.153,11
Unit price
per
Tax included.
Electricity just like from the socket – even far from shore: The Victron Phoenix Inverter 12/3000 converts your 12V onboard battery into clean 230V AC with a pure sine wave output. With 3000 VA rated power and exceptionally high peak power, it effortlessly powers sensitive devices on board – from coffee machines to laptops.
Tip: Ensure adequately dimensioned DC cables and fuses between the battery and the inverter – with 3000 VA, currents of over 250 A can flow in the 12V system. Victron recommends using the associated Victron battery monitor for precise charge level monitoring.
Couldn't load pickup availability
brand:
Victron Energy
Availability:
Low stock
SKU:
OB-BB-PIN123020000
Product group:
category:
electrical system
Regular price
€1.153,11
Regular price
Sale price
€1.153,11
- Pure sine wave output – safe for all sensitive 230V appliances on board
- 3000 VA rated power with high peak power reserve for high-demand devices
- High efficiency due to combination of high-frequency and line-frequency technology
- VE.Bus interface for networking, monitoring and system integration with other Victron components
- Scalable: up to six units can be connected in parallel in single, split-phase or three-phase operation
- 12V input – suitable for typical marine electrical systems
| Brand | Victron Energy |
|---|---|
| Series | Phoenix Inverter |
| Model | 12/3000 230 V VE.Bus |
| Input Voltage | 12 V DC |
| Rated Power | 3000 VA |
| Output Voltage | 230 V AC |
| Output Waveform | Pure Sine Wave |
| Interface | VE.Bus |
| Parallel Operation | Up to 6 units (1-phase, split-phase, 3-phase) |
| Technology | High Frequency + Line Frequency (Combination) |
Victron Energy
Gewicht (ca.): 20.1 kg
