Victron MultiPlus 24/3000/70-50 230V VE.Bus
The Victron MultiPlus 24/3000/70-50 combines a true sine wave inverter and a powerful battery charger in a single device – ideal for self-sufficient power supply on board. With 3000 VA inverter power, a 70 A charging current and the proven VE.Bus interface for flexible system integration, you are perfectly equipped for demanding onboard electrical systems. The adaptive charging function and PowerAssist technology ensure that your batteries are charged gently and that shore power or generator are never overloaded.
Tip: With the Victron Color Control GX or another compatible VE.Bus control panel, the MultiPlus can be conveniently monitored and configured remotely – ideal for more complex onboard systems with solar and alternator.
Couldn't load pickup availability
- True sine wave inverter with 3000 VA – reliably powers sensitive electronics and household appliances
- Integrated charger with 70 A charging current for fast, gentle battery charging
- PowerAssist technology – peak load support prevents overload of shore power or generator
- Adaptive charging function extends battery life through intelligent adjustment of the charging curve
- VE.Bus interface enables parallel connection, three-phase operation, and easy system integration
- Uninterrupted switching between shore power and battery operation
| Model | MultiPlus 24/3000/70-50 |
|---|---|
| System Voltage | 24 V |
| Inverter Power | 3000 VA |
| Charge Current | 70 A |
| Shore Power Output Rated Current | 50 A |
| Output Voltage | 230 V |
| Output Waveform | True Sine Wave |
| Charging Technology | Adaptive, multi-stage |
| Technology | PowerAssist (Hybrid) |
| Interface | VE.Bus |
| System Integration | Parallel connection / Three-phase operation possible |
Victron Energy
Gewicht (ca.): 20.9 kg
