By Vetus
Vetus Push-Pull Cable 2.0m
Regular price
€66,13
Regular price
Sale price
€66,13
Unit price
per
Tax included.
Precise control, even on long and winding paths: The Vetus LF type push-pull cable transmits control movements with minimal friction – thanks to a ribbed plastic sheath around the core, which reduces contact with the outer casing to a minimum. This keeps the control smooth and direct, even with complex cable routings.
When installing, maintain a minimum bending radius of 165 mm – tighter bends increase friction and can impair smooth operation.
Couldn't load pickup availability
Regular price
€66,13
Regular price
Sale price
€66,13
- Ribbed plastic jacket reduces internal friction – smooth control over long distances
- High strength combined with great flexibility – ideal for tight cable routing on board
- Particularly suitable for long and complicated installations as well as dual-station setups
- Minimum bending radius of 165 mm allows tight curves
- Standard 10-32 (M5) thread for easy integration into common control systems
| Type | LF (Low Friction) |
|---|---|
| Length | 3.0 m |
| Nominal Stroke | 75 mm |
| Minimum Bend Radius | 165 mm |
| Pull Length | 76.2 mm (3") |
| Standard Thread | 10-32 (M5) |
| Available Lengths | 0.5 m to 10 m; up to 17 m by order |
| Special Feature | Ribbed plastic casing to minimise friction |
Vetus
Gewicht (ca.): 0.58 kg
