By Vetus
Vetus Fuel Connection Kit 51mm-8mm
Regular price
€203,49
Regular price
Sale price
€203,49
Unit price
per
Tax included.
One single hole, all connections at once: The Vetus connection set type FTL combines the filler pipe, vent, suction pipe, return line, and fuel gauge flange in a single lid – saving you considerable time during installation. The anodized, saltwater-resistant aluminum lid with a rubber gasket seals securely and permanently against fuel.
Tip: Cut the 114 mm mounting hole cleanly and without burrs using a hole saw so that the rubber gasket lies flat and is compressed evenly – this is the key to a permanently leak-proof connection.
Couldn't load pickup availability
Regular price
€203,49
Regular price
Sale price
€203,49
- All-in-one: Filler hose, vent, dip tube, return, and tank sender flange combined in one lid
- Only one mounting hole (Ø 114 mm) required – reduces drilling effort and potential leaks
- Anodized, saltwater-resistant aluminum lid with rubber seal for a permanently tight connection
- 3-screw mounting compresses the seal evenly – quick and reliable installation
- Suitable for plastic, metal, and GRP tanks as well as diesel and gasoline
- Includes mounting tabs for securing the tank and terminal strip for the ground conductor
| Type | FTL |
|---|---|
| Filler Hose Connection | Ø 51 mm |
| Tank Vent | Ø 16 mm |
| Fuel Suction Tube | Ø 8 mm |
| Fuel Return | Ø 8 mm |
| Mounting Hole Diameter | Ø 114 mm |
| Maximum Tank Depth | 440 mm |
| Sender Flange | 5-hole SAE flange |
| Terminal Block | 6.3 mm (for ground wire) |
| Lid Material | Anodized aluminum, saltwater resistant |
| Gasket | Rubber gasket |
| Fastening | 3 screws |
| Compatible Tank Materials | Plastic, Metal, GRP |
| Fuel Type | Diesel and Gasoline |
Vetus
Gewicht (ca.): 1.48 kg
