By Vetus

Vetus Flexible Coupling BULLFLEX4 for 30mm Shaft

€694,13
€694,13
Tax included.

More driving comfort through reduced vibrations: The Vetus Bullflex 1 is a specially developed flexible coupling that efficiently dampens torsional vibrations between the engine and the propeller shaft. The super elastic, pre-tensioned rubber element ensures a play-free, silent connection – even at low speeds and varying engine loads.

Tip: Vetus supplies suitable mounting material for attachment to the gearbox separately – ask for the appropriate accessories when ordering. The centering ring can be removed if necessary to facilitate installation in confined spaces.
brand: Vetus
Availability: Low stock
SKU: OB-BB-BULFL0430
Product group:
category:
Engine technology
BEPBEP Bus Bar Double 6x 4mm Screw
BEP Bus Bar Double 6x 4mm Screw
Vetus Kühlwasserfilter-Kit Typ 330
VetusVetus Cooling Water Filter Kit Type 330, 19mm
Vetus Flexible Kupplung BULLFLEX4 für 30mm Welle
€694,13
€694,13

  • Super-elastic rubber element efficiently dampens torsional vibrations – for noticeably quieter engine operation
  • Backlash-free connection between engine and shaft ensures low-noise running
  • Axial and radial fail-safes protect the connection even in case of overload
  • Angular misalignment up to 2° permissible – shaft remains centered even with misalignment and in reverse operation
  • Built-in thrust bearing and no conical clamping hub for easy assembly and disassembly
  • 4" connection (models 1, 2 and 4) – suitable for common gearboxes

Model Bullflex 1
Shaft diameter 25 mm
Connection port 4"
Permissible angular deviation 2°
Fail-safe device axial and radial
Thrust bearing integrated
Clamping hub no tapered clamping hub
Suitable for V-drives No
Compatible gearboxes (Model 32) Hurth, Velvet, TD, ZF, P.R.M.
Brand Vetus

Vetus

Gewicht (ca.): 7.42 kg
