By Vetus

Vetus Flush Hatch, Square 515x515mm

€676,60
€676,60
Tax included.

No bulk, no tripping hazard, no wind noise: The Vetus FGHF5151 fits absolutely flush with the deck, giving your boat a clean, modern silhouette. The 12 mm thick, dark smoke-colored acrylic glass and the polished aluminum frame add a clear VIP accent – inside and out.

Tip: The cutout must have a corner radius of exactly 43 mm – plan for this from the start when working on the deck to achieve a clean, gap-free result.
brand: Vetus
Availability: Low stock
SKU: OB-BB-FGHF5151
Product group:
category:
Hatches & Fans
CrossevenCrosseven Braided Polyester Rope
Crosseven Geflochtenes Polyesterseil
Hella Apelo A2 RGB Alu
Hella MarineHella Apelo A2 RGB Aluminum, Anthracite, Blister
Vetus flächenbündige Luke
€676,60
€676,60

  • Completely flush installation – no protruding handles, stiles or hinges, no jammed catches
  • 12 mm dark smoke-coloured acrylic glass – high-quality look and pleasant light dimming
  • Polished, anodised aluminium frame – stylish and permanently maintenance-free
  • Can be opened from the outside with a winch handle – ideal for hard-to-reach positions
  • Suitable for design category A, area II – sealed watertight with VETUS latches
  • Easy-to-clean, smooth surface without undercuts

Model FGHF5151
Outer dimensions 580 × 580 mm
Cut-out dimensions 507 × 507 mm
Corner radius cut-out 43 mm
Shape Square
Glazing 12 mm acrylic glass, dark smoked
Frame Polished, anodised aluminum frame
Opening from outside Possible with winch crank handle
Design category Category A, Area II
Comparable with Lewmar 399604995
Comparable with Bomar N3680-10

Vetus

Gewicht (ca.): 8.95 kg
