By Vetus

Vetus Bow Thruster Panel with Buttons 12/24V

€207,45
€207,45
Tax included.

Precise control over bow and stern thrusters directly at the helm: The Vetus control panel type BP brings the control of your thruster into a compact, waterproof mounting frame with clever protection logic. Thanks to a time delay for thrust reversal, automatic shut-off functions, and integrated child safety, it reliably protects the motor and drive from incorrect operation and overload.

Tip: Use the integrated output switch (max. 3 A) to connect, for example, a maneuvering light or a horn in parallel – so you have everything on one panel when docking.
brand: Vetus
Availability: Low stock
SKU: OB-BB-BPAS
Product group:
category:
Engine Technology,Equipment
PlastimoPLASTIMO TRANSOCEAN ISAF 8-PERSON LIFERAFT >24H SOLAS
PLASTIMO RETTUNGSINSEL TRANSOCEAN ISAF 8P >24H CO
Hempel's Multicoat Pale Cream 0
HempelHempel's Multicoat Pale Cream 0.75
Vetus Bugschraubenpanel mit Tastern 12/24V
€207,45
€207,45

  • Time delay for reverse thrust – protects the jet rudder from abrupt load changes
  • Automatic shutdown after 30 minutes of inactivity – no accidental standby discharge of the battery
  • Automatic shutdown after more than 2 minutes of continuous operation, reset after 5 seconds – prevents overheating
  • Child lock – prevents unintentional activation on board
  • Integrated output switch (max. 3 A) for switching other consumers
  • Waterproof aluminum design, fits into standard cutout Ø 52 mm – quick and clean installation

Power Supply 12/24 V
Type BP (Bow thruster control panel with push buttons)
Version Models BPAS and BPAJ
Material Aluminium
Bezel 97 × 95 mm
Mounting Depth 90 mm
Cut-out Size Ø 52 mm (standard cut-out)
Output Switch max. 3 A (for switching other devices)
Time Delay Reversing Thrust Yes
Auto Shut-off Inactivity After 30 minutes
Auto Shut-off Continuous Operation After 2 minutes, reset after 5 seconds
Child Safety Lock Integrated
Protection Class Waterproof
Compatibility Retroactively compatible with other Vetus bow thruster panels

Vetus

Gewicht (ca.): 0.28 kg
