By Yacht Devices

UAB Wi-Fi Router, 2 NMEA-0183 inputs and outputs

€343,90
€343,90
Tax included.

Connect your onboard instruments wirelessly to a tablet, smartphone, or laptop – the Yacht Devices YDNR-02N makes it possible. The compact router translates between NMEA 2000, NMEA-0183, and SeaTalk, making all data available via Wi-Fi for navigation apps and web browsers. No more protocol chaos: a single device connects all your onboard technology.

Tip: In access point mode, multiple mobile devices can be connected simultaneously – ideal if the skipper and navigator are working with different apps. All active data connections can be monitored live in the browser, which significantly simplifies troubleshooting in case of unclear data displays.
brand: Yacht Devices
Availability: Low stock
SKU: OB-BB-YDNR-02N
Product group:
category:
Navigation & Audio
MastervoltMastervolt Easy Charge, 6A-1
Mastervolt Easy Charge
Hempel's Brilliant Gloss Black 0
HempelHempel's Brilliant Gloss Black 0.75
Navigation & Audio
€343,90
€343,90

  • Supports NMEA 2000, NMEA 0183 and SeaTalk – connects devices with different protocols and data rates
  • Built-in web server: configuration, data viewing and firmware updates directly in the browser – no additional software required
  • Automatic track and data recording in internal memory with export as GPX, XML or CSV
  • Flexible routing and filtering: freely assign data between all inputs and outputs as well as TCP/UDP servers
  • Access point or client mode: create your own WLAN network or integrate into an existing network
  • Free NMEA 2000 diagnostic software for Windows, macOS and Linux included

Model YDNR-02N
NMEA 2000 Port 1 × input and output
NMEA 0183 Ports 2 × input, 2 × output
SeaTalk Port 1 × input
Data Services 3 × TCP/UDP Data Servers
Web Server Built-in (configuration, display, firmware update)
Wi-Fi Standard 2.4 GHz – 802.11 b/g/n
Wi-Fi Range Up to 50 m (outdoors)
Wi-Fi Modes Access Point / Client (integration into existing network)
Data Logging Automatic – GPX, XML, CSV Export
Max. Current Consumption 60 mA (all NMEA 0183 inputs with 100 Ω resistance)
Dimensions (L × W × H) 85 × 45 × 28 mm (without antenna)
Programmable Yes
