By Yacht Devices

UAB Voyage Recorder, NMEA2000

€284,05
€284,05
Tax included.

Record every trip completely: The Yacht Devices Voyage Recorder YDVR-04N automatically records all data from your NMEA 2000 network – GPS, wind, depth, temperature, AIS, heel and more – onto a Micro SD card. Whether for regatta analysis, a digital logbook or proof of the storm of the season: everything is available on demand.

Tip: Use a Class 10 Micro SD card with 16–32 GB for optimal writing speed and maximum recording duration. If you want to automatically save weather forecasts from your VHF radio, simply connect the radio to the line-in input – the software automatically links the audio recordings to the corresponding GPS positions.
brand: Yacht Devices
Availability: Low stock
SKU: OB-BB-YDVR-04N
Product group:
category:
Navigation & Audio
Victron EnergyVictron M8 Circular Connector Plug/Socket Cable 2m
Victron M8 Rundstecker Stecker/Buchse Kabel 2m
EPIFANES Mono-Urethane Mittelgrau 3212 750ml
EpifanesEPIFANES Mono-Urethane Medium Gray 3212 750ml
UAB Voyage Recorder
€284,05
€284,05

  • Records all NMEA 2000 message types - GPS, AIS, wind, depth, temperature, heel and other onboard network data
  • Up to 100-200 sailing days on a 16 GB Micro SD card (Class 10 recommended)
  • Audio input (3.5 mm jack, line-in) for VHF radio recording or voice logbook
  • Export to GPX, CSV, XML, Signal K, OpenSkipper and many more - compatible with Google Earth, Garmin, Raymarine and common open-source software
  • Automatic logbook creation as a printable, multi-page ODF document with a single click
  • Extremely power-efficient with an average consumption of only 23 mA

Model YDVR-04N
Network Interface NMEA 2000® / Raymarine SeaTalkNG (Micro connector)
Recorded Data All NMEA 2000 message types (GPS, wind, depth, temperature, AIS, heel, etc.)
Storage Medium MicroSD card (recommended: Class 10, 16-32 GB)
Estimated Capacity approx. 100-200 sailing days (16 GB card)
Audio Input 3.5 mm jack, Line-In, adjustable sensitivity and activation level
Audio Format WAV
Export Formats GPX, CSV, XML, ODF (logbook), CAN, OpenSkipper, CanBoat, Signal K
Compatible Software Voyage Recorder Software (Windows, Mac OS X, Linux), Google Earth, Garmin MapSource, OpenSkipper, CAN Log Viewer
Supply Voltage 10-16 V
Average Current Consumption 23 mA
Case Length (without connectors) 54 mm
