By Yacht Devices

UAB Switch Control

€147,25
€147,25
Tax included.

Full control over your vessel's electrical circuits – directly on the panel and over the network: The YDSC-04N is the switch control unit that connects up to four LED-illuminated push buttons with the YDCC-04N relay control unit, thus combining physical switching and NMEA 2000 remote control. Compactly built, easy to install, and ready to use without special knowledge, it also fits on small boats.

Tip: For wireless operation from the cockpit or saloon, combine it with a Yacht Devices WiFi Gateway – then you can conveniently access all circuits via your smartphone's browser, without an additional app.
brand: Yacht Devices
Availability: Low stock
SKU: OB-BB-YDSC-04N
Product group:
category:
Navigation & Audio
VetusVetus Hose Connection 32 mm
Vetus Bullauge PZ661
VetusVetus Porthole PZ661, Aluminum, Category A1
Navigation & Audio
€147,25
€147,25

  • Direct control of the four relay channels of the YDCC-04N via connected push buttons – simultaneously controllable via NMEA 2000
  • Compatible with all NMEA 2000 devices that support PGN 127501 and 127502 – not just YDCC-04
  • Free choice of push buttons – use the buttons that match your boat's existing switch panel
  • Expandable to up to 252 circuits in the network – grows with your boat's requirements
  • Firmware updates can be installed via WiFi or USB gateway; free PC software available
  • Power supply directly via the NMEA 2000 network – no separate wiring required

Model YDSC-04N
Relay Channels (Controllable) 4
Button Connections 4 (LED illuminated buttons, not included)
NMEA 2000 Certification NMEA 2000® Certified
Supported PGNs 127501, 127502
Compatibility Yacht Devices YDCC-04N and other NMEA 2000 Digital Switching devices
Max. Expandable Circuits 252
Power Supply 7–16 V via NMEA 2000 network
Power Consumption max. 30 mA
Dimensions (L × W × H) 85 × 45 × 28 mm
Firmware Update Via WiFi or USB Gateway
Software Free PC software available

Yacht Devices
