By Yacht Devices

UAB Run Indicator

€246,05
€246,05
Tax included.

Keep an eye on the operational status of all important onboard consumers: The YDRI-04N measures current and voltage of up to four circuits and displays their status directly on your chartplotter or another NMEA 2000 display. This allows you to see at a glance whether pumps, lights, or solar panels are working correctly – and you will be immediately warned if something is wrong.

Tip: Use the flexible switching rules to trigger an automatic warning if the bilge pump activates unusually frequently – a reliable early warning system for a developing leak.
brand: Yacht Devices
Availability: Low stock
SKU: OB-BB-YDRI-04N
Product group:
category:
Navigation & Audio
EpifanesEPIFANES Mono-Urethane Pearl White 3253 750ml
EPIFANES Mono-Urethane Pearl White 3253 750ml
Yachticon 3-Kammer Flachschlauch 15 m
YachticonYachticon 3-Chamber Flat Hose 15 m
UAB Run Indicator
€246,05
€246,05

  • Monitors 4 channels simultaneously – current up to 10 A continuous load (15 A peak) and up to 40 V per channel
  • Direct display on the multifunction display via NMEA 2000 (PGN 127508) – no additional shunt required
  • Flexible alarm rules automatically detect leaks, forgotten faucets or continuously running pumps
  • Control of digital switching devices (incl. alarm button) possible
  • CZone compatible and easily accessible via WiFi gateway or WiFi router
  • Compact design (85 × 45 × 28 mm) with NMEA 2000 connector and 10 wire terminals (AWG 14) – ready for installation

Model YDRI-04N
Number of Channels 4
Max. Voltage per Channel 40 V
Max. Continuous Current per Channel 10 A
Max. Peak Current per Channel 15 A
Max. Solar Power per Channel 200 W
Power Supply 7–16 V (NMEA 2000)
NMEA 2000 Current Consumption max. 60 mA
NMEA 2000 PGN 127508
CZone Compatible Yes
WiFi Access Via WiFi Gateway or WiFi Router
Software Update Via CAN Log Viewer
Connections NMEA 2000 Connector + 10 Wire Terminals (AWG 14)
Dimensions (L × W × H) 85 × 45 × 28 mm
