By Yacht Devices
UAB NMEA 2000 Digital Thermometer, NMEA2000
Regular price
€147,25
Regular price
Sale price
€147,25
Unit price
per
Tax included.
Temperature everywhere on board – precise and directly to the network. The Yacht Devices YDTC-14N measures gases and liquids in the range of –55 °C to +125 °C and feeds the values into your NMEA 2000 or SeaTalkNG network. This way, the temperature appears on any compatible chartplotter or display, without additional wiring.
Tip: Plan the sensor extension with shielded cable to avoid measurement inaccuracies due to electromagnetic interference sources on board. The configuration of the temperature channel is done via the NMEA 2000 network and can be adjusted at any time.
Couldn't load pickup availability
brand:
Yacht Devices
Availability:
Low stock
SKU:
OB-BB-YDTC-14N
Product group:
category:
Navigation & Audio
Regular price
€147,25
Regular price
Sale price
€147,25
- Wide measuring range from -55 °C to +125 °C – for outside air, refrigerator, engine room and more
- Sensor in sealed stainless steel sleeve – robust, corrosion-resistant and suitable for gas and liquid measurement
- 95 cm long sensor cable ex works, extendable up to 100 m if required
- Freely configurable: temperature channel selectable (air, water, refrigerator, engine room, baitwell, etc.)
- Dual connection: NMEA 2000 and SeaTalkNG – fits most modern onboard systems
- Transmits readings directly to existing network displays, no separate display unit required
| Model | YDTC-14N |
|---|---|
| Measurement Range | –55 °C to +125 °C |
| Sensor | Sealed stainless steel sleeve, outside the enclosure |
| Sensor Cable Length (from factory) | 95 cm |
| Max. Cable Extension | 100 m |
| Network Connection | NMEA 2000 |
| Additional Connection | SeaTalkNG |
| Connectivity | WLAN (Wi-Fi) |
| Configurable Temperature Channels | Air temperature, water temperature, refrigerator temperature, engine room temperature, livewell temperature, and many more |
| Sensor Application Range | Gases and liquids |
Yacht Devices
