By Yacht Devices

UAB NMEA-0183 WI-FI Router

€284,05
€284,05
Tax included.

On-board devices, plotters, smartphones, and tablets connected at once: The YDWR-02 from Yacht Devices combines four NMEA-0183 ports and one SeaTalk1 input into a compact Wi-Fi router. You can stream instrument data wirelessly to any device on board – and maintain full control over each individual data channel.

Tip: Individual NMEA data sets per port can be deactivated via the filter function in the web browser – practical for reducing data noise on older plotters with limited processing speed.
brand: Yacht Devices
Availability: Low stock
SKU: OB-BB-YDWR-02
Product group:
category:
Navigation & Audio
HempelHempel's Brilliant Gloss Radiant Red 0.75
Hempel's Brilliant Gloss Radiant Red 0
Plastimo KID FOAM LIFE JACKET
PlastimoPlastimo KID FOAM LIFE JACKET
Navigation & Audio
€284,05
€284,05

  • 4 NMEA-0183 ports plus SeaTalk1 input – connects almost any onboard electronics in one device
  • Galvanically isolated port (2,500 VRMS) protects sensitive devices from ground loops
  • SeaTalk1 translation: Data and autopilot control directly accessible via NMEA-0183
  • Configuration via web browser on smartphone or tablet – no app, no drivers needed
  • Tunnel mode per port and data source: also transmits Navtex data and NMEA-0183 sentences without checksum
  • Two or more devices work as Wi-Fi extension and allow multiple end devices simultaneously

Model YDWR-02
NMEA 0183 Ports 4 (of which 1 galvanically isolated, 2,500 VRMS)
SeaTalk1 Port 1 (input for SeaTalk1 network)
Wi-Fi Standard 802.11 b/g/n, 2.4 GHz
Wi-Fi Range approx. 30 m
Average Power Consumption 47 mA
Dimensions (without antenna) 85 × 48 × 28 mm
Configuration Via web browser (smartphone, tablet, PC)
Tunnel Mode Configurable per port and data source
Supported Protocols NMEA 0183, SeaTalk1, $STALK data records, Navtex

Yacht Devices
