By Yacht Devices

UAB NMEA-0183 Multiplexer

€189,05
€189,05
Tax included.

End the data chaos on board: The YDNM-02 from Yacht Devices bundles up to five NMEA-0183 sources and one SeaTalk1 network in a compact device – and all without a laptop or special software. Thanks to six pre-configured standard settings and a one-click configuration using a paperclip, it's ready for use in minutes.

Tip: For configuration, a simple paperclip is enough to press the button – hold the paperclip down while switching on to toggle between the six standard profiles. This saves you from needing a laptop even during initial installation.
brand: Yacht Devices
Availability: Low stock
SKU: OB-BB-YDNM-02
Product group:
category:
Navigation & Audio
HempelHempel's Brilliant Gloss Cobalt Blue 0.75
Hempel's Brilliant Gloss Cobalt Blue 0
Victron MultiPlus 12/800/35-16 230V VE.Bus
Victron EnergyVictron MultiPlus 12/800/35-16 230V VE.Bus
UAB NMEA-0183 Multiplexer
€189,05
€189,05

  • 5 x NMEA-0183 inputs (including galvanically isolated port with 2,500 Vrms) for maximum device combinations
  • SeaTalk1 input with bidirectional data exchange – even autopilot commands are transmitted
  • Automatic baud rate detection (AUTO Speed) on each port – no manual setting required
  • 6 pre-configured standard profiles selectable via push button – setup without PC and software
  • Flexible filters and routing rules per input for clean, targeted data distribution
  • Tunnel mode for non-standard devices and NAVTEX receivers

Model YDNM-02
NMEA 0183 Inputs 5 × (2 × TX/RX, 1 × TX/RX with galvanic isolation 2,500 Vrms, 2 × RX only)
NMEA 0183 Protocols RS-232 single-ended and RS-422 differential
SeaTalk1 Input 1 × (bidirectional, with autopilot support)
Baud Rate 300 to 115,200 baud, AUTO Speed possible
Preconfigured Profiles 6 standard settings
Filter Per input by dataset number, NMEA 0183 sentence format, or Talker ID
Tunnel Mode Yes, for non-standard devices and NAVTEX
Power Supply 7 – 16 V
Power Consumption 60 mA (all inputs loaded with 100 Ω)
Receiver Input Fusing Port 1, 2, 3, 5: 12 kΩ / Port 4: 96 kΩ
Dimensions (L × W × H) 85 × 45 × 28 mm
