No more rigid cable connections: The Circuit Control YDCC-04N from Yacht Devices brings digital switching to your onboard electrical system. Four bistable relays can be controlled via an illuminated push-button, the NMEA 2000 network, or even directly from the chartplotter – and remain in the selected state after switching, without any continuous power consumption.
Tip: Bistable relays retain their switching state even after a power failure. When setting up for the first time, check the state of all relays after power-up and additionally secure critical consumers.
Couldn't load pickup availability
brand:
Yacht Devices
Availability:
Low stock
SKU:
OB-BB-YDCC-04
Product group:
category:
Navigation & Audio
Regular price
€312,55
Regular price
Sale price
€312,55
- Four bistable relays (2 x ON switches, 2 x CHANGE-OVER switches) – no holding current after switching, minimal self-consumption
- 10 A continuous current per channel (20 A peak/4 s) – suitable for typical on-board consumers
- Switches DC and AC up to 400 V, isolated up to 5,000 V RMS – also suitable for 230 V on-board power systems
- CZone support for Garmin, B&G, Simrad, Furuno and Raymarine Axiom/eS/gS
- Fully NMEA 2000 certified, compatible with PGN 127501/127502 – fits into any standard-compliant network
- Power supply directly via the NMEA 2000 network – no separate power cable required
| Model | YDCC-04N |
|---|---|
| Switching Channels | 4 (2 × ON switches, 2 × Change-over switches) |
| Relay Type | Bistable |
| Continuous Current per Channel | 10 A |
| Peak Current per Channel | 20 A (4 s, max. 10 % of the time) |
| Switching Voltage | DC and AC up to 400 V |
| Isolation Voltage | 5,000 V RMS |
| Own Consumption (Continuous Current) | 30 mA |
| Own Consumption (Peak Current) | 130 mA |
| Power Supply | 7–16 V via NMEA 2000 bus |
| Network | NMEA 2000® (certified) |
| Supported PGNs | PGN 127501, PGN 127502 |
| CZone Support | Garmin, B&G, Simrad, Furuno, Raymarine Axiom/eS/gS |
| Dimensions (L × W × H) | 92 × 72 × 38 mm |
