By Ocean Birds

TriScan Clamp HAS64 090-114mm

€4,73
€4,73
Tax included.

Reliable even where saltwater, vibration and weather take their toll on materials: The TriScan HAS28 is a high-quality hose clamp made of stainless steel for demanding use on board. With its perforated band and recessed hex screw, it sits securely and can be tightened even in tight installation situations.

Tip: Tighten the screw with a calibrated torque wrench to the reference value of 4.5 Nm (40 in-lbs) – this will prevent overtightening and at the same time ensure optimal sealing force.
brand: Ocean Birds
Availability: In stock
SKU: OB-BB-2620064706
Product group:
category:
Engine technology
philippiPhilippi Strip Fuse STS 50A (ANL)
Philippi Streifensicherung STS 50A (ANL)
Philippi Sicherungshalter ASH6
philippiPhilippi Fuse Holder ASH6
TriScan Schelle HAS64 090-114mm
€4,73
€4,73

  • Completely made of stainless steel (DIN 1.4310 / AISI 301) – corrosion-resistant even in saltwater applications
  • Perforated band (width 12.7 mm) for uniform clamping force over the entire circumference
  • Stainless steel hex screw with slot (5/16" / 8 mm, DIN 1.4303 / AISI 305) for secure tightening
  • Clamping range 33–57 mm – fits a variety of common hose sizes on board
  • Reference tightening torque 4.5 Nm – defined tightening without overtightening

Clamping Range 33–57 mm
Band Material Stainless Steel DIN 1.4310 / AISI 301, perforated
Band Width 12.7 mm
Housing Material Stainless Steel DIN 1.4310 / AISI 301
Screw Material Stainless Steel DIN 1.4303 / AISI 305
Screw Type Hex-head screw with slot
Screw Head Size 5/16" / 8 mm
Tightening Torque (approx.) 4.5 Nm / 40 in-lbs

Ocean Birds

Gewicht (ca.): 0.52 kg
