TriScan Clamp HAS12 018-032mm
Regular price
€2,74
Regular price
Sale price
€2,74
Unit price
per
Tax included.
Reliably holds even where saltwater, vibration, and weather conditions take their toll on the material: The TriScan HAS28 is a high-quality stainless steel hose clamp for demanding applications on board. With its perforated band and recessed hex screw, it sits securely and can be tightened even in confined installation situations.
Tip: Tighten the screw to a reference value of 4.5 Nm (40 in-lbs) with a calibrated torque wrench – this prevents overtightening and at the same time ensures optimal sealing force.
Couldn't load pickup availability
brand:
Ocean Birds
Availability:
In stock
SKU:
OB-BB-2620012706
Product group:
category:
Engine technology
Regular price
€2,74
Regular price
Sale price
€2,74
- Made entirely of stainless steel (DIN 1.4310 / AISI 301) – corrosion-resistant even in saltwater applications
- Perforated band (width 12.7 mm) for uniform clamping force over the entire circumference
- Stainless steel hex screw with notch (5/16" / 8 mm, DIN 1.4303 / AISI 305) for secure tightening
- Clamping range 33–57 mm – fits a variety of common hose sizes on board
- Recommended tightening torque 4.5 Nm – defined tightening without overtightening
| Clamping range | 33–57 mm |
|---|---|
| Band material | Stainless steel DIN 1.4310 / AISI 301, perforated |
| Band width | 12.7 mm |
| Housing material | Stainless steel DIN 1.4310 / AISI 301 |
| Screw material | Stainless steel DIN 1.4303 / AISI 305 |
| Screw type | Hex head screw with slot |
| Screw head size | 5/16" / 8 mm |
| Tightening torque (guideline) | 4.5 Nm / 40 in-lbs |
Ocean Birds
Gewicht (ca.): 0.22 kg
