By Shakespeare
Shakespeare PL259 Connectors
Regular price
€20,15
Regular price
Sale price
€20,15
Unit price
per
Tax included.
The right termination for your VHF antenna cable: This gold-plated brass PL259 connector from Shakespeare securely connects your RG58 coaxial cable with strong signal to your marine radio or plotter. Thanks to the included UG175 adapter and DooDad strain relief, the connector is precisely matched to the thinner RG58 cable cross-section.
Tip: Carefully solder the inner conductor connection and clean the contact surfaces before assembly – gold-plated contacts only conduct optimally when they are grease-free and clean.
Couldn't load pickup availability
brand:
Shakespeare
Availability:
In stock
SKU:
OB-BB-PL-259-58-G
Product group:
category:
Navigation & Audio
Regular price
€20,15
Regular price
Sale price
€20,15
- Gold-plated brass for corrosion-resistant, permanently secure connection on board
- Perfect fit for RG58 coaxial cable – no play, no signal loss at the connection point
- UG175 adapter included – allows the PL259 connector to be used with the thinner RG58 cable
- DooDad strain relief included – protects the solder joint from mechanical stress
- Type PL-259-58-G – common industry standard for marine VHF antenna connections
| Type | PL-259-58-G |
|---|---|
| Connector Standard | PL259 (SO239 compatible) |
| Material | Gold Plated Brass |
| Cable Type | RG58 Coaxial Cable |
| Included Adapter | UG175 (for RG58) |
| Strain Relief | DooDad |
Shakespeare
Gewicht (ca.): 0.11 kg
