By Ritchie Navigation
Ritchie Voyager, flush mount, black, black
Regular price
€212,42
Regular price
Sale price
€212,42
Unit price
per
Tax included.
Precisely on course, day and night: The Ritchie Voyager is a flush-mount marine compass with a flat PowerDamp dial and integrated green NiteVu lighting. It can be easily installed in an 82mm hole and provides a fast, stable course indication even in rough seas, thanks to powerful DirectiveForce magnets.
Tip: The mounting hole must be at least 82mm and at most 107mm to ensure the fastening screws have a secure hold. In the case of offset mounting or if a screw dome protrudes from the housing, the minimum dimension of 82mm is sufficient. Use the appropriate mounting gasket VY-0164 for a clean, watertight seal.
Couldn't load pickup availability
brand:
Ritchie Navigation
Availability:
Low stock
SKU:
OB-BB-F-82
Product group:
category:
Navigation & Audio
Regular price
€212,42
Regular price
Sale price
€212,42
- PowerDamp flat dial with open dial design – steady, easy-to-read display even in rough seas
- Integrated green NiteVu night lighting – preserves night vision perception when steering
- DirectiveForce magnets for fast and precise course acquisition
- Integrated compensators for easy deviation correction directly on the compass
- Movable sunshade and 45-degree lubber lines for optimal readability
- High-temperature composite construction – extended operating temperature range, 100% repairable
| Dial Diameter | 76 mm (3″) |
|---|---|
| Mounting Hole Size | 82 mm (3 ½″) to max. 107 mm (4 3/16″) |
| Mounting Type | Flush Mount |
| Dial Type | PowerDamp Flat Dial, open |
| Lighting | Integrated NiteVu Night Lighting, Green |
| Operating Voltage Lighting | Standard 12 V (24 V and 32 V optionally available) |
| Magnet System | DirectiveForce Magnets |
| Compensators | Integrated (Deviation Correction) |
| Sun Shield | Movable, integrated |
| Lubber Lines | 45 Degrees |
| Housing Material | High-Temperature Composite |
| Optics | Scientifically Matched Sapphire Jewel Bearing |
| Dial Movement | Hardened Steel |
| Housing Color | Black |
| Dial Color | Black |
| Shipping Weight | approx. 680 g |
| Warranty | 5 Years (Ritchie) |
| Repairability | 100% Repairable |
| Replacement Lighting 12 V Green | SH-0195 KIT |
| Replacement Lighting 12 V Red | SH-0202 KIT |
| Replacement Lighting 24 V Green | SH-0213 ASY |
| Mounting Gasket | VY-0164 |
Ritchie Navigation
Gewicht (ca.): 1.44 kg
