Ritchie Sport, black, blue dial
Small, precise, and ready for immediate use: The RitchieSport fits into any standard instrument hole and provides you with a clear, direct reading – by day and, thanks to integrated NiteVu lighting, also by night. For sport boats where every inch counts, it's the clever navigation reference on the dashboard.
Tip: X-23 models do not have built-in compensators. When installing, check that disturbing magnetic sources (speakers, electrical cables) are sufficiently distanced from the compass to minimize deviation errors. The green 12V lighting can be replaced with optional lamps in red, clear, or blue if desired – part numbers are listed in the specification table below.
Couldn't load pickup availability
- Fits 2 1/16″ (5.50 cm) standard instrument holes – installs quickly without modification
- Direct-reading, 51 mm (2") dial – for at-a-glance readings
- View angle adjustable up to 30 degrees – adapts flexibly to your sitting position
- Exclusive green NiteVu lighting (12 V) – safely navigate at night anytime
- DirectiveForce magnets and hardened steel pivot dial movement – reliable heading even with vibration
- High-temperature composite construction – extended operating temperature range for harsh marine conditions
| Dial Diameter | 2″ (51 mm) |
|---|---|
| Mounting Size (Cutout) | 2 1/16″ (5.50 cm) |
| Readout | Direct Read |
| Viewing Angle | Adjustable up to 30 Degrees |
| Lighting | Built-in NiteVu Lighting, 12 V, Green (Standard) |
| Magnet Type | DirectiveForce Magnets |
| Dial Movement | Hardened Steel Pivot Dial Movement |
| Optics | Scientifically Matched Sapphire Jewel |
| Housing | High-Temperature Composite Construction |
| Compensator | Not Included (Model X-23) |
| Color / Dial | Black / Black |
| Warranty | 5 Years (Ritchie Exclusive) |
| Shipping Weight (Approx.) | 142 g (5 oz.) |
| Replacement Bulb 12 V Green | RS-0148 GRN |
| Replacement Bulb 12 V Red | RS-0148 RED |
| Replacement Bulb 12 V Clear | RS-0148 WHT |
| Replacement Bulb 12 V Blue | RS-0148 BLU |
Ritchie Navigation
