By Ritchie Navigation
Ritchie Explorer with bracket mount, black
Regular price
€100,03
Regular price
Sale price
€100,03
Unit price
per
Tax included.
The Ritchie Explorer is the classic handheld compass for the cockpit – robust, quickly readable, and can be mounted or removed in seconds. With its bracket mounting and wing screws, it can be flexibly attached to fittings and stowed away again immediately if needed.
Tip: The compass is supplied with 12-volt illumination as standard. If you need 6 V or 24 V, suitable replacement bulbs are available from Ritchie. For compensation, it is recommended to create a deviation table after measuring the deflection.
Couldn't load pickup availability
brand:
Ritchie Navigation
Availability:
Low stock
SKU:
OB-BB-B-51
Product group:
category:
Navigation & Audio
Regular price
€100,03
Regular price
Sale price
€100,03
- 70mm Direct Reading Dial – read at a glance even in rough seas
- Removable bracket mount with thumbscrews – installs or stores in seconds
- Internal green night lighting for safe course taking even after sunset
- Built-in compensators to easily correct deviation right on the compass
- DirectiveForce Magnets for fast heading lock-on
- High-temperature composite construction for extended operating range
- 100% repairable – exclusive 5-year warranty from Ritchie Navigation
| Dial Diameter | 70 mm (2 ¾") |
|---|---|
| Dial Color | Black |
| Readout | Direct Read |
| Lighting | Internal, Green, 12V (Standard); 6V and 24V Optional |
| Mounting | Bracket Mount with Thumbscrews, Removable |
| Sun Shield | Movable, Built-in |
| Compensators | Built-in |
| Magnetic System | DirectiveForce |
| Optics | Scientifically Matched Sapphire Jewel |
| Dial Movement | Hardened Steel Pivot |
| Case Material | High-Temperature Composite |
| Repairability | 100% Repairable |
| Warranty | 5 Years (Ritchie Navigation) |
| Protective Cover | None |
| Shipping Weight | Approx. 454 g (1 lb.) |
| Replacement Light 6V | EX-0099-2 |
| Replacement Light 12V | EX-0005-2 |
| Replacement Light 24V | EX-0099 |
| Light & Wire Assembly 12V | EX-0022 ASY |
Ritchie Navigation
Gewicht (ca.): 0.94 kg
