By PSS

PSS seal 80 mm shaft, 4 1/2" stern tube

€1.559,24
€1.559,24
Tax included.

No more dripping stuffing boxes: The PSS Shaft Seal Type A is a low-maintenance mechanical face seal that provides a completely watertight seal for your propeller shaft. It reliably compensates for misalignment, vibrations, and the axial fore and aft movement caused by propeller thrust – with no dripping water in the bilge.

Tip: Correct bellows pre-tensioning is crucial for proper function. After installation, check the compression of the bellows and ensure that the rotor's set screws are resting on clean, degreased shaft metal. After the first few hours of operation, recheck all hose clamps for a secure fit.
brand: PSS
Availability: Low stock
SKU: OB-BB-02-80M-412
Product group:
category:
Engine technology
GuidiGuidi Ball Valve FF - G 1''1/2
Guidi Kugelhahn FF - G 1''1/2
Vetus Kabelschuhe für 50 mm² / M6
VetusVetus Cable Lugs for 50 mm² / M6
Motor-Technik
€1.559,24
€1.559,24

  • Mechanical face seal – no dripping, no readjustment like with conventional stuffing boxes
  • Floating carbon flange automatically compensates for misalignments and shaft vibrations
  • Pre-stressed stainless steel rotor keeps sealing surface in contact even with changing propeller thrust
  • O-rings rotate with the shaft – no wear on the shaft surface during operation
  • Wide temperature range from –15 °C to +107 °C for year-round use
  • Robust materials: Carbon graphite lapped to 4 HLB, rotor made of 316 SS / Nitronic 50

Type PSS Mechanical Seal Type A
Shaft Diameter 50 mm
Stern Tube Inner Diameter 3″
Sealing Principle Mechanical face seal (rotating stainless steel rotor / stationary carbon flange)
Rotor Material 316 SS / Nitronic 50, 9 Ra surface finish
Carbon Flange Carbon-graphite, lapped to 4 HLB (tolerance 0.000 011 mm)
Bellows Material Molded Nitrile – PVC
Rotor Sealing to Shaft 2 O-rings (rotating, no wear in operation)
Temperature Limits –15 °C to +107 °C
Pressure Limit 1 bar (15 PSI)
Max. Shaft Speed 10 000 rpm
Carbon Flange Fastening Hose clamps to bellows and stern tube
Rotor Fastening Set screws on shaft

PSS

Gewicht (ca.): 0.11 kg
