By PSS

PSS Seal 25 mm Shaft, 1 1/2' Stern Tube

€439,01
€439,01
Tax included.

No more dripping stuffing boxes: The PSS Shaft Seal Type A is a low-maintenance mechanical face seal that seals your propeller shaft passage absolutely watertight. It reliably compensates for misalignments, vibrations, and the axial forward and backward movement caused by propeller thrust – with no dripping water in the bilge.

Tip: The correct preload of the bellows is crucial for proper function. After installation, check the compression of the bellows and ensure that the set screws of the rotor rest on clean, degreased shaft metal. After the first few hours of operation, recheck all hose clamps for a secure fit.
brand: PSS
Availability: Low stock
SKU: OB-BB-02-25M-112
Product group:
category:
Engine technology
VetusVetus Plastic Water Collector
Motor-Technik
Hella Wasserdichte Steckverbindungen
Hella MarineHella Waterproof Connectors
PSS
€439,01
€439,01

  • Mechanical face seal – no dripping, no readjustment like with conventional stuffing boxes
  • Floating carbon flange automatically compensates for misalignments and shaft vibrations
  • Pre-tensioned stainless steel rotor keeps sealing surface in permanent contact even with changing propeller thrust
  • O-rings rotate with the shaft – no wear on the shaft surface during operation
  • Wide temperature range from –15 °C to +107 °C for year-round use
  • Robust materials: carbon-graphite lapped to 4 HLB, rotor made of 316 SS / Nitronic 50

Type PSS Mechanical Seal Type A
Shaft Diameter 50 mm
Stern Tube Inner Diameter 3″
Sealing Principle Mechanical face seal (rotating stainless steel rotor / stationary carbon flange)
Rotor Material 316 SS / Nitronic 50, 9 Ra surface finish
Carbon Flange Carbon-graphite, lapped to 4 HLB (tolerance 0.000 011 mm)
Bellows Material Molded Nitrile – PVC
Rotor Sealing to Shaft 2 O-rings (rotating, no wear in operation)
Temperature Limits –15 °C to +107 °C
Pressure Limit 1 bar (15 PSI)
Max. Shaft Speed 10 000 rpm
Carbon Flange Attachment Hose clamps to bellows and stern tube
Rotor Attachment Set screws on the shaft

PSS

Gewicht (ca.): 1.05 kg
