By PSS

PSS Shaft Seal 20 mm Shaft, 2" Stern Tube

€421,69
€421,69
Tax included.

No more dripping stuffing boxes: The PSS Shaft Seal Type A is a low-maintenance mechanical face seal that absolutely watertight seals your propeller shaft passage. It reliably compensates for misalignments, vibrations, and the axial fore-and-aft movement due to propeller thrust – without any dripping water in the bilge.

Tip: The correct preload of the bellows is crucial for perfect function. After installation, check the compression of the bellows and ensure that the set screws of the rotor rest on clean, degreased shaft metal. After the first hours of operation, recheck all hose clamps for a tight fit.
brand: PSS
Availability: Low stock
SKU: OB-BB-02-20M-200
Product group:
category:
Engine technology
Victron EnergyVictron Zigbee to USB converter
Victron Zigbee zu USB Konverter
Plastimo Regattaboje aufblasbar
PlastimoPlastimo Inflatable Racing Buoy, orange, H: 1.6 m
PSS-Dichtung 20 mm Welle
€421,69
€421,69

  • Mechanical face seal – no dripping, no need for readjustment as with traditional stuffing boxes
  • Floating carbon flange automatically compensates for misalignments and shaft vibrations
  • Pre-tensioned stainless steel rotor keeps the sealing surface in constant contact even with changing propeller thrust
  • O-rings rotate with the shaft – no wear on the shaft surface during operation
  • Wide temperature range from –15 °C to +107 °C for year-round use
  • Robust materials: carbon-graphite lapped to 4 HLB, rotor made of 316 SS / Nitronic 50

Type PSS Shaft Seal Type A
Shaft Diameter 50 mm
Stern Tube Inner Diameter 3″
Sealing Principle Mechanical Face Seal (Rotating Stainless Steel Rotor / Stationary Carbon Flange)
Rotor Material 316 SS / Nitronic 50, 9 Ra Surface Finish
Carbon Flange Carbon Graphite, lapped to 4 HLB (0.000011 mm Tolerance)
Bellows Material Molded Nitrile – PVC
Rotor Sealing to Shaft 2 O-Rings (Rotating, No Wear in Operation)
Temperature Limits –15 °C to +107 °C
Pressure Limit 1 bar (15 PSI)
Max. Shaft Speed 10,000 RPM
Carbon Flange Mounting Hose Clamps on Bellows and Stern Tube
Rotor Mounting Set Screws on Shaft

PSS

Gewicht (ca.): 0.11 kg
