By PSS

PSS seal for 2' shaft, 3' stern tube

€961,58
€961,58
Tax included.

No more dripping stuffing boxes: The PSS Shaft Seal Type A is a low-maintenance mechanical face seal that completely watertight seals your propeller shaft passage. It reliably compensates for misalignments, vibrations, and the axial fore and aft movement caused by propeller thrust – with no drip water in the bilge.

Tip: Correct bellow pre-tension is crucial for proper function. After installation, check the bellow's compression and ensure that the rotor's set screws rest on clean, degreased shaft metal. After the first few hours of operation, re-check all hose clamps for a secure fit.
brand: PSS
Availability: Low stock
SKU: OB-BB-02-200-300
Product group:
category:
Engine technology
PlastimoPLASTIMO Mooring Pole
PLASTIMO Haltestange für Festmacher
Motor-Technik
VetusOld Tiller Pin 30mm
PSS-Dichtung 2' Welle
€961,58
€961,58

  • Mechanical seal – no dripping, no readjustment like with classic stuffing boxes
  • Floating carbon flange automatically compensates for misalignments and shaft vibrations
  • Pre-tensioned stainless steel rotor keeps sealing surface in constant contact even with changing propeller thrust
  • O-rings rotate with the shaft – no wear on the shaft surface during operation
  • Wide temperature range from –15 °C to +107 °C for year-round use
  • Robust materials: carbon-graphite lapped to 4 HLB, rotor made of 316 SS / Nitronic 50

Type PSS Mechanical Seal Type A
Shaft Diameter 50 mm
Stern Tube Inner Diameter 3″
Sealing Principle Mechanical face seal (rotating stainless steel rotor / stationary carbon flange)
Rotor Material 316 SS / Nitronic 50, 9 Ra surface finish
Carbon Flange Carbon-graphite, lapped to 4 HLB (tolerance 0.000 011 mm)
Bellows Material Molded Nitrile – PVC
Rotor Sealing to Shaft 2 O-rings (rotating, no wear in operation)
Temperature Limits –15 °C to +107 °C
Pressure Limit 1 bar (15 PSI)
Max. Shaft Speed 10,000 RPM
Carbon Flange Mounting Hose clamps on bellows and stern tube
Rotor Mounting Set screws on the shaft

PSS

Gewicht (ca.): 0.11 kg
