By PSS

PSS Seal 1 1/8" Shaft, 1 3/4" Stern Tube

€439,01
€439,01
Tax included.

No more dripping stuffing boxes: The PSS Shaft Seal Type A is a low-maintenance mechanical face seal that provides a completely watertight seal for your propeller shaft. It reliably compensates for misalignment, vibrations, and the axial fore and aft movement caused by propeller thrust – with no dripping water in the bilge.

Tip: Correct bellows pre-tensioning is crucial for proper function. After installation, check the bellows compression and ensure that the rotor's set screws rest on clean, degreased shaft metal. After the first few hours of operation, recheck all hose clamps for a secure fit.
brand: PSS
Availability: Low stock
SKU: OB-BB-02-118-134
Product group:
category:
Engine technology
VetusVetus Exhaust Riser FE, Stainless Steel, 261-485 mm
Vetus Aussteller FE
Steyr PROFILSCHELLE
Steyr MotorsSteyr PROFILE CLAMP
PSS
€439,01
€439,01

  • Mechanical face seal – no dripping, no readjustment like with classic stuffing boxes
  • Floating carbon flange automatically compensates for misalignments and shaft vibrations
  • Pre-tensioned stainless steel rotor keeps sealing surface in permanent contact even with changing propeller thrust
  • O-rings rotate with the shaft – no wear on the shaft surface during operation
  • Wide temperature range from –15 °C to +107 °C for year-round use
  • Robust materials: carbon-graphite lapped to 4 HLB, rotor made of 316 SS / Nitronic 50

Type PSS Shaft Seal Type A
Shaft Diameter 50 mm
Stern Tube ID 3″
Sealing Principle Mechanical Face Seal (rotating stainless steel rotor / stationary carbon flange)
Rotor Material 316 SS / Nitronic 50, 9 Ra surface finish
Carbon Flange Carbon-Graphite, lapped to 4 HLB (tolerance 0.000 011 mm)
Bellow Material Molded Nitrile – PVC
Rotor Seal to Shaft 2 O-rings (rotating, no wear in operation)
Temperature Limits –15 °C to +107 °C
Pressure Limit 1 bar (15 PSI)
Max. Shaft Speed 10,000 rpm
Carbon Flange Attachment Hose clamps on bellows and stern tube
Rotor Attachment Set screws on the shaft

PSS

Gewicht (ca.): 0.11 kg
