By Plastimo
PLASTIMO Deck Hatch Alu/Acrylic 567x437
Regular price
€512,58
Regular price
Sale price
€512,58
Unit price
per
Tax included.
Light and fresh air into the ship's interior – reliably and watertight. This deck hatch from Plastimo combines a sturdy aluminum frame with a 10 mm thick acrylic pane, ensuring optimal brightness below deck while providing a solid seal. The telescopic stay holds the hatch securely in any open position, so you don't have to readjust it.
Tip: Before installation, thoroughly clean and degrease the sealing surface. Use a UV-resistant sealant for outdoor use to achieve permanently watertight results.
Couldn't load pickup availability
Regular price
€512,58
Regular price
Sale price
€512,58
- Stable aluminum frame with 10 mm acrylic pane for durable use in saltwater environments
- Telescopic stay holds the hatch securely in the desired open position
- Aluminum hinges for long-lasting, low-maintenance function
- Low installation height below deck of only 15 mm – space-saving interior
- Inside dimensions 505 × 375 mm for generous light and air incidence
| External dimensions | 567 × 437 mm |
|---|---|
| Internal dimensions (clear opening) | 505 × 375 mm |
| Cut-out dimensions | 507 × 377 mm |
| Frame material | Aluminum |
| Panel thickness | 10 mm (acrylic) |
| Hinges | Aluminum |
| Standoffs | Telescopic |
| Installation height below deck | 15 mm |
| Frame radius | 42.5 mm |
Plastimo
Gewicht (ca.): 6.83 kg
