By Plastimo
PLASTIMO Deck Hatch Aluminum/Acrylic 320x320
Regular price
€331,07
Regular price
Sale price
€331,07
Unit price
per
Tax included.
Light and fresh air into the boat – without compromising on watertightness and stability. The Plastimo deck hatch combines a robust aluminum frame with a 10 mm thick acrylic pane and can be securely fixed in any open position thanks to a telescopic stay. Compact to install, reliable in everyday use on board.
Tip: Before installation, thoroughly degrease the sealing surface and frame contact surface and seal all around with a UV-resistant marine sealant – this extends the life of the seal and reliably prevents water ingress.
Couldn't load pickup availability
brand:
Plastimo
Availability:
Low stock
SKU:
OB-BB-63883
Product group:
category:
Hatches & Vents, Rigging & Deck
Regular price
€331,07
Regular price
Sale price
€331,07
- Aluminium frame – corrosion-resistant and durable in saltwater environments
- 10 mm thick acrylic pane for good light transmission and high impact resistance
- Telescopic support holds the hatch securely in the chosen open position
- Low installation height of only 15 mm below deck – ideal for flat deck superstructures
- Aluminum hinges for play-free, durable operation
- Inner dimensions 320 × 320 mm with a compact cut-out dimension of 258 × 258 mm
| Internal dimensions | 320 × 320 mm |
|---|---|
| Cut-out dimensions | 258 × 258 mm |
| Pane thickness | 10 mm |
| Pane material | Acrylic |
| Frame material | Aluminum |
| Hinges | Aluminum |
| Hold-open device | Telescopic support |
| Installation height below deck | 15 mm |
| Corner radius | 42.5 mm |
Plastimo
Gewicht (ca.): 3.06 kg
