By philippi
Philippi UTV 80
Regular price
€109,25
Regular price
Sale price
€109,25
Unit price
per
Tax included.
No more clogged floats and sticking linkages: The Philippi UTV 80 measures your tank's fill level via ultrasound – completely contactless and without a single moving part inside the tank. It is the clean, low-maintenance solution on board, especially for holding tanks and greywater tanks.
Tip: In case of heeling or choppy water while underway, the ultrasonic measurement can become inaccurate – this is due to physics. For better measurement quality even while underway, Philippi recommends the optional installation of a sound guide tube UFT. The UTV 80 is generally not suitable for fuel tanks.
Couldn't load pickup availability
brand:
philippi
Availability:
Low stock
SKU:
OB-BB-702193580
Product group:
category:
electrical system
Regular price
€109,25
Regular price
Sale price
€109,25
- Non-contact ultrasonic technology – no moving parts in the tank, no fouling, no jamming
- Ideal for blackwater and greywater tanks where conventional senders quickly fail
- Compatible with analog and digital measuring instruments – universally applicable
- Direct replacement for existing tank senders with SAE standard mounting (5 holes, 53 mm bolt circle)
- Wide supply range 10–30 V – suitable for 12 V and 24 V vehicle electrical systems
- Extreme temperature range from -40 °C to 85 °C for continuously reliable operation
| Type | Philippi UTV 80 |
|---|---|
| Measurement principle | Ultrasonic, non-contact |
| Suitable for | Greywater tanks, holding tanks |
| Compatibility | Analog and digital measuring instruments |
| Mounting | SAE standard, 5 holes, bolt circle 53 mm |
| Supply voltage | 10–30 V |
| Current consumption | 50 mA |
| Temperature range | −40 °C to 85 °C |
| Accessories (optional) | Sound guide tube UFT for improved measurement while underway |
philippi
Gewicht (ca.): 0.08 kg
