By philippi

Philippi Fuse Box STB 8-Way w. Cover

€82,80
€82,80
Tax included.

Eight circuits neatly protected without sacrificing much space: The Philippi STB 8-way is a compact surface-mount blade fuse holder that reliably protects up to eight small consumers and measuring lines. The included cover keeps moisture and dirt away – ideal for use on board.

Tip: Label the individual fuse positions immediately after installation – this makes it easy to identify the correct fuse in the event of a fault.
brand: philippi
Availability: Low stock
SKU: OB-BB-700105046
Product group:
category:
electrical system
International YachtfarbenInternational Liquid Rubbing 500 ml
International Liquid Rubbing 500 ml
International Interdeck Blau 750 ml
International YachtfarbenInternational Interdeck Blue 750 ml
Philippi Sicherungsblock STB 8 Fach m. Abdeckung
€82,80
€82,80

  • 8 independent fuse positions for small loads and test leads
  • Designed for blade fuses up to 30 A each – wide range of applications
  • Ignition protected according to ISO 8846 and SAE J1171 – tested for use in flammable atmospheres
  • Protective cover included – protects fuses from moisture and unintentional contact
  • Compact design for space-saving surface mounting in control cabinets or companionways

Type Philippi BS 5046
Fuse Slots 8-way
Fuse Type Blade Fuse
Max. Fusing per Channel 30 A
Mounting Type Surface Mount
Ignition Protected ISO 8846 / SAE J1171
Dimensions (L × W × D) 146 × 44 × 33 mm
Cover Included

philippi

Gewicht (ca.): 0.18 kg
