By philippi
Philippi MCS 12V Plug 12V
Regular price
€22,33
Regular price
Sale price
€22,33
Unit price
per
Tax included.
Secure connection, clean disconnection: The Philippi MCS magnetic connector holds reliably thanks to magnetic force and detaches in a controlled manner under tension – ideal for all 12V and 24V consumers on board. The silver-plated contacts ensure low contact resistance and permanently secure power transmission.
Tip: When connecting, carefully twist the wire ends after stripping and tighten the screw terminals firmly – this will keep the contact resistance low in the long term.
Couldn't load pickup availability
brand:
philippi
Availability:
Low stock
SKU:
OB-BB-600111012
Product group:
category:
electrical system
Regular price
€22,33
Regular price
Sale price
€22,33
- Suitable for 12 V and 24 V – versatile for use throughout the vehicle electrical system
- Rated current 16 A – sufficient for common onboard consumers
- Silver-plated contact surface for minimal contact resistance and corrosion resistance
- Screw terminal for secure, tool-supported cable connection up to 2.5 mm²
- Wide temperature range –25 to +85 °C – reliable in all seasons
| Type | Philippi MCS |
|---|---|
| Rated voltage | 12 V / 24 V |
| Rated current | 16 A |
| Connection cross-section | max. 2.5 mm² |
| Contact surface | silver-plated |
| Connection type | Screws |
| Temperature range | –25 … +85 °C |
| Housing material | Plastic |
| Dimensions | Ø 37 × L 84 × H 18 mm |
philippi
Gewicht (ca.): 0.02 kg
Herstellerinformationen gemäß GPSR:
PHILIPPI ELEKTRISCHE SYSTEME GMBHNECKARAUE 19
71686 REMSECK
