Philippi ETA Circuit Breaker 16A 1140-F114-P1
Compact protection for your onboard electrical circuits: The Philippi E-T-A 1140-F114-P1 is a single-pole thermal circuit breaker in a compact design that reliably trips before a short circuit or overcurrent can cause damage. Thanks to its snap-action mechanism and trip-free release, it switches off safely – regardless of whether the switch is currently being operated or not. After tripping, it can be easily reset manually, thus permanently replacing a fuse.
Tip: When installing, make sure to select the correct rated current for the respective circuit – the circuit breaker is available in rated current ranges from 2 to 16 A. This type is particularly suitable for DC systems over 12/24 V (up to DC 48 V).
Couldn't load pickup availability
- Thermal overcurrent protection with snap-action mechanism – precise, reliable switching behavior
- Trip-free release – trips even when the button is held down
- Manually resettable – no fuse replacement necessary
- Compact design for installation in Series 100 panels
- Suitable for DC 48 V and AC 240 V – flexible use on board
- Compliant with EN 60934 (Circuit-Breakers for Equipment standard)
| Type | E-T-A 1140-F114-P1M1 |
|---|---|
| Design | Single pole, thermal overcurrent circuit breaker |
| Construction | Miniature design |
| Current rating range | 2–16 A |
| Voltage DC | 48 V |
| Voltage AC | 240 V |
| Trip mechanism | Snap-action mechanism with trip-free release |
| Standard | EN 60934 |
| Panel cut-out | 22 × 11.3 mm |
| Reset | Manual |
| Suitable for | Philippi switch panel Series 100 |
