Philippi ESD 12/24 Built-in Standard Socket with Cover
Regular price
€6,04
Regular price
Sale price
€6,04
Unit price
per
Tax included.
Power wherever you need it – the Philippi ESD 12/24 is the robust flush-mounted solution for standard and universal plugs on board. The integrated protective cover keeps dust and splashes away when the socket is not in use. This keeps the contact clean and the connection reliable – even in a humid onboard environment.
Tip: Before installation, check the thread length (8 mm) against the material thickness of your switch panel – for thicker panels, you may need to shim it from the inside to ensure a tight and wobble-free fit.
Couldn't load pickup availability
brand:
philippi
Availability:
In stock
SKU:
OB-BB-367607100
Product group:
category:
electrical system
Regular price
€6,04
Regular price
Sale price
€6,04
- Suitable for standard and universal plugs – broad compatibility with common onboard equipment
- Protective cap against dust and splash water – protects the contact when not in use
- Loadable up to 16 A at 6–24 V – equally suitable for 12 V and 24 V onboard electrical systems
- Compact installation dimensions (mounting hole Ø 16 mm) – can be integrated space-savingly in dashboards or panels
- Connection via flat connectors 6.3 mm – fast and secure wiring without soldering
| Type | ESD 12/24 |
|---|---|
| Design | Flush-mount standard socket with protective cover |
| Suitable for | Standard and universal plugs |
| Max. Current Load | 16 A |
| Voltage Range | 6–24 V |
| Mounting Hole Diameter | 16 mm |
| Thread Length | 8 mm |
| Connection | Flat plug 6.3 mm |
philippi
Gewicht (ca.): 0.02 kg
Herstellerinformationen gemäß GPSR:
PHILIPPI ELEKTRISCHE SYSTEME GMBHNECKARAUE 19
71686 REMSECK
